Fast Multi-Instantiation
 |
This task shows you how to repeat components using the parameters previously set in the Define Multi_Instantiation command. | |
 |
You will use the Fast
Multi-Instantiation command to quickly repeat the component of your choice. The operation
is very simple. Make sure the option Work with the cache system is deactivated (for more refer to Working with a Cache System) and open the Fast_Multi_Instantiation.CATProduct document. |
|
 |
1. | Select the component you wish to instantiate, that is CRIC_BRANCH_3. |
 |
||
| 2. | Click the Fast Multi-Instantiation icon  . |
|
 |
The shortcut Ctrl + D calls the command too. | |
| The result is immediate. Three components are created according to the parameters defined in the Multi-Instantiation dialog box. | ||
 |
||
 |
||
 |
||
